400KHZ M12 Ultrasonic Sensor
Original price was: $28.00.$25.00Current price is: $25.00.
| Item No.: | F400K-M18 |
| Operating Frequency: | 400kHz ± 2% |
| Echo Sensitivity: | -78dB Min. (0dB = 100Vpp, 10Bursts,30cm) |
| Capacitance at 1 kHz: | 260 pF ± 20% |
| Min.Sensing Range: | 20 mm |
| Typical Sensing Range: | 20 to 500mm |
| Directivity: | 6° ± 2° |
| Max. Driving Voltage: | 300 Vpp,(2% Duty Cycle Tone Burst) |
| Operating Temperature: | -40 ℃ to 90℃ |
| Weight: | 1g |
| Housing Material: | Copper/Plastic |
| Acoustic Window: | Glass reinforced epoxy |
| Case Color: | Green/Black/Blue |
1000 in stock
CompareDescription
| Item No.: | F400K-M12 |
| Operating Frequency: | 400kHz ± 2% |
| Echo Sensitivity: | -78dB Min. (0dB = 100Vpp, 10Bursts,30cm) |
| Capacitance at 1 kHz: | 260 pF ± 20% |
| Min.Sensing Range: | 20 mm |
| Typical Sensing Range: | 20 to 500mm |
| Directivity: | 6° ± 2° |
| Max. Driving Voltage: | 300 Vpp,(2% Duty Cycle Tone Burst) |
| Operating Temperature: | -40 ℃ to 90℃ |
| Weight: | 1g |
| Housing Material: | Copper/Plastic |
| Acoustic Window: | Glass reinforced epoxy |
| Case Color: | Green/Black/Blue |
Tag: Ultrasonic Sensor
Additional information
| Weight | 1 kg |
|---|---|
| Dimensions | 15 × 15 × 6 cm |
